1.5-Layer Quasigeostrophic (QG) Model¶

This notebook simulates the 1.5-layer (or "equivalent barotropic") Quasigeostrophic (QG) model. This is a fundamental model in geophysical fluid dynamics for studying the interaction of large-scale ocean or atmospheric eddies with planetary waves (Rossby waves).

Equation¶

The full QG PV equation (in terms of total PV $q_\text{total} = q' + \beta y$) is: $$\frac{\partial q_\text{total}}{\partial t} + J(\psi, q_\text{total}) = \nu \nabla^{2n} q_\text{total} + F$$

The state variable evolved here is the PV anomaly $q' = q_\text{total} - \beta y$: $$\frac{\partial q'}{\partial t} + J(\psi, q') = -\beta v + \nu \nabla^{2n} q' + F$$

Where:

• $q'$ is the PV anomaly (state variable).
• $\psi$ is the geostrophic streamfunction.
• $J(\psi, q')$ is the Jacobian (advection of PV anomaly).
• $-\beta v$ is the beta-plane term.
• $\nu$, $n$, and $F$ are viscosity, hyperviscosity order, and forcing.

PV Inversion¶

The key inversion relationship is: $$q' = \nabla^2\psi - \frac{1}{R^2}\psi$$

where $R$ is the Rossby radius of deformation. This is solved as a Helmholtz equation via SpectralHelmholtzSolver2D.

Numerical Method¶

• PV Inversion: Solve $(\nabla^2 - 1/R^2)\psi = q'$ in Fourier space.
• Time Integration: Semi-implicit (IMEX) with diffrax.KenCarp4.

In [ ]:

import math
import pathlib
from pathlib import Path
from typing import Annotated

import cyclopts
import diffrax
import equinox as eqx
import jax
import jax.numpy as jnp
import jax.random as jrandom
import matplotlib
import matplotlib.pyplot as plt
import xarray as xr
from jaxtyping import Array, Float
from loguru import logger
from tqdm import tqdm

matplotlib.use("Agg")

from spectraldiffx import FourierGrid2D
from spectraldiffx import SpectralDerivative2D
from spectraldiffx import SpectralHelmholtzSolver2D

# JAX configuration
jax.config.update("jax_enable_x64", True)

IMG_DIR = Path(__file__).resolve().parent.parent / "docs" / "images" / "qg_model"
IMG_DIR.mkdir(parents=True, exist_ok=True)

app = cyclopts.App()

import math import pathlib from pathlib import Path from typing import Annotated import cyclopts import diffrax import equinox as eqx import jax import jax.numpy as jnp import jax.random as jrandom import matplotlib import matplotlib.pyplot as plt import xarray as xr from jaxtyping import Array, Float from loguru import logger from tqdm import tqdm matplotlib.use("Agg") from spectraldiffx import FourierGrid2D from spectraldiffx import SpectralDerivative2D from spectraldiffx import SpectralHelmholtzSolver2D # JAX configuration jax.config.update("jax_enable_x64", True) IMG_DIR = Path(__file__).resolve().parent.parent / "docs" / "images" / "qg_model" IMG_DIR.mkdir(parents=True, exist_ok=True) app = cyclopts.App()

1. Parameter and State Management¶

In [ ]:

class Params(eqx.Module):
    """Simulation parameters."""

    nu: float  # Kinematic viscosity (nu)
    nv: int = eqx.field(static=True)  # Hyperviscosity order (n)
    beta: float  # Planetary vorticity gradient (beta)
    r_def_inv_sq: float  # Inverse squared Rossby radius of deformation (1/R^2)
    grid: FourierGrid2D = eqx.field(static=True)
    deriv: SpectralDerivative2D = eqx.field(static=True)
    solver: SpectralHelmholtzSolver2D = eqx.field(static=True)
    forcing: Float[Array, "Ny Nx"] | None  # Forcing term F


class State(eqx.Module):
    """The state of the simulation: the potential vorticity field `q`."""

    q: Float[Array, "Ny Nx"]

class Params(eqx.Module): """Simulation parameters.""" nu: float # Kinematic viscosity (nu) nv: int = eqx.field(static=True) # Hyperviscosity order (n) beta: float # Planetary vorticity gradient (beta) r_def_inv_sq: float # Inverse squared Rossby radius of deformation (1/R^2) grid: FourierGrid2D = eqx.field(static=True) deriv: SpectralDerivative2D = eqx.field(static=True) solver: SpectralHelmholtzSolver2D = eqx.field(static=True) forcing: Float[Array, "Ny Nx"] | None # Forcing term F class State(eqx.Module): """The state of the simulation: the potential vorticity field `q`.""" q: Float[Array, "Ny Nx"]

2. Helper Functions¶

In [ ]:

@eqx.filter_jit
def get_psi_and_uv_from_q(q: Float[Array, "Ny Nx"], p: Params):
    """
    Computes streamfunction and velocity from Potential Vorticity (PV) anomaly.
    1. Solve (laplacian - 1/R^2)psi = q directly (q is the PV anomaly q' = q_total - beta*y).
    2. Compute u = -d(psi)/dy and v = d(psi)/dx.

    Note: The beta*y planetary vorticity is NOT subtracted here because q already
    represents the PV anomaly. Subtracting beta*y (a non-periodic linear ramp) from
    the Helmholtz RHS would introduce Gibbs ringing and cause NaN instability.
    """
    psi = p.solver.solve(q, alpha=p.r_def_inv_sq)
    dpsi_dx, dpsi_dy = p.deriv.gradient(psi)
    u, v = -dpsi_dy, dpsi_dx
    return psi, u, v

@eqx.filter_jit def get_psi_and_uv_from_q(q: Float[Array, "Ny Nx"], p: Params): """ Computes streamfunction and velocity from Potential Vorticity (PV) anomaly. 1. Solve (laplacian - 1/R^2)psi = q directly (q is the PV anomaly q' = q_total - beta*y). 2. Compute u = -d(psi)/dy and v = d(psi)/dx. Note: The beta*y planetary vorticity is NOT subtracted here because q already represents the PV anomaly. Subtracting beta*y (a non-periodic linear ramp) from the Helmholtz RHS would introduce Gibbs ringing and cause NaN instability. """ psi = p.solver.solve(q, alpha=p.r_def_inv_sq) dpsi_dx, dpsi_dy = p.deriv.gradient(psi) u, v = -dpsi_dy, dpsi_dx return psi, u, v

3. The Right-Hand-Side (RHS) of the PDE¶

In [ ]:

def explicit_term(t: float, y: State, args: Params) -> State:
    """
    Computes the explicit part of the RHS: Advection + Beta-plane term + Forcing.
    RHS_exp = -J(psi, q) - beta*v + F

    The beta-plane effect is incorporated as -beta*v (= J(psi, beta*y) in the
    doubly-periodic formulation), avoiding direct use of the non-periodic beta*y field.
    """
    del t  # Autonomous equation
    q = y.q

    # Get streamfunction and velocity from PV
    _, u, v = get_psi_and_uv_from_q(q, args)

    # Advection of PV: -(u dot grad)q
    advection = -args.deriv.advection_scalar(u, v, q)

    # Beta-plane term: replaces J(psi, beta*y) = beta * dpsi/dx = beta * v
    beta_term = -args.beta * v

    # Add forcing if provided
    rhs = advection + beta_term
    rhs = rhs + args.forcing if args.forcing is not None else rhs

    return State(q=rhs)


def implicit_term(t: float, y: State, args: Params) -> State:
    """
    Computes the implicit part of the RHS: Diffusion.
    RHS_imp = nu * laplacian^n(q)

    The Laplacian is computed directly in spectral space WITHOUT dealiasing,
    because the implicit operator must be a clean linear operator for the IMEX
    solver to invert correctly. Applying dealiasing here would cause mode mismatch
    at the dealiased boundary, leading to instability and NaN.
    """
    del t  # Autonomous equation
    q_hat = args.grid.transform(y.q)
    K2 = args.grid.K2
    # Apply (-K2)^nv in spectral space for laplacian^nv, without dealiasing
    lap_hat = ((-K2) ** args.nv) * q_hat
    diffusion = args.grid.transform(lap_hat, inverse=True).real
    return State(q=args.nu * diffusion)

def explicit_term(t: float, y: State, args: Params) -> State: """ Computes the explicit part of the RHS: Advection + Beta-plane term + Forcing. RHS_exp = -J(psi, q) - beta*v + F The beta-plane effect is incorporated as -beta*v (= J(psi, beta*y) in the doubly-periodic formulation), avoiding direct use of the non-periodic beta*y field. """ del t # Autonomous equation q = y.q # Get streamfunction and velocity from PV _, u, v = get_psi_and_uv_from_q(q, args) # Advection of PV: -(u dot grad)q advection = -args.deriv.advection_scalar(u, v, q) # Beta-plane term: replaces J(psi, beta*y) = beta * dpsi/dx = beta * v beta_term = -args.beta * v # Add forcing if provided rhs = advection + beta_term rhs = rhs + args.forcing if args.forcing is not None else rhs return State(q=rhs) def implicit_term(t: float, y: State, args: Params) -> State: """ Computes the implicit part of the RHS: Diffusion. RHS_imp = nu * laplacian^n(q) The Laplacian is computed directly in spectral space WITHOUT dealiasing, because the implicit operator must be a clean linear operator for the IMEX solver to invert correctly. Applying dealiasing here would cause mode mismatch at the dealiased boundary, leading to instability and NaN. """ del t # Autonomous equation q_hat = args.grid.transform(y.q) K2 = args.grid.K2 # Apply (-K2)^nv in spectral space for laplacian^nv, without dealiasing lap_hat = ((-K2) ** args.nv) * q_hat diffusion = args.grid.transform(lap_hat, inverse=True).real return State(q=args.nu * diffusion)

4. Initial Condition & Forcing Setup¶

In [ ]:

def generate_initial_pv(grid: FourierGrid2D, seed: int = 42) -> jnp.ndarray:
    """
    Generates a random initial PV field with energy in a specific
    wavenumber band, suitable for triggering baroclinic instability.
    """
    key = jrandom.PRNGKey(seed)
    noise = jrandom.normal(key, shape=(grid.Ny, grid.Nx))
    q_hat = grid.transform(noise)

    # Band-pass filter to initialize turbulence around the deformation scale
    k_mag = jnp.sqrt(grid.K2)
    k_def = 2 * math.pi / (grid.Lx * 0.1)  # Rough deformation wavenumber
    k_min, k_max = k_def * 0.8, k_def * 1.2
    mask = (k_mag > k_min) & (k_mag < k_max)
    q_hat = jnp.where(mask, q_hat, 0.0)

    # Transform back and normalize
    q0 = grid.transform(q_hat, inverse=True).real
    return 1e-1 * q0 / jnp.std(q0)  # Scale to be a small perturbation

def generate_initial_pv(grid: FourierGrid2D, seed: int = 42) -> jnp.ndarray: """ Generates a random initial PV field with energy in a specific wavenumber band, suitable for triggering baroclinic instability. """ key = jrandom.PRNGKey(seed) noise = jrandom.normal(key, shape=(grid.Ny, grid.Nx)) q_hat = grid.transform(noise) # Band-pass filter to initialize turbulence around the deformation scale k_mag = jnp.sqrt(grid.K2) k_def = 2 * math.pi / (grid.Lx * 0.1) # Rough deformation wavenumber k_min, k_max = k_def * 0.8, k_def * 1.2 mask = (k_mag > k_min) & (k_mag < k_max) q_hat = jnp.where(mask, q_hat, 0.0) # Transform back and normalize q0 = grid.transform(q_hat, inverse=True).real return 1e-1 * q0 / jnp.std(q0) # Scale to be a small perturbation

5. Main Simulation Logic¶

In [ ]:

@app.default
def run_qg_model(
    nx: Annotated[
        int, cyclopts.Parameter("--nx", help="Number of grid points in x-direction.")
    ] = 128,
    ny: Annotated[
        int, cyclopts.Parameter("--ny", help="Number of grid points in y-direction.")
    ] = 128,
    domain_length: Annotated[
        float, cyclopts.Parameter("--length", help="Length of the square periodic domain.")
    ] = 1.0,
    viscosity: Annotated[
        float, cyclopts.Parameter("--viscosity", help="Kinematic viscosity (nu).")
    ] = 2e-12,
    hyperviscosity_order: Annotated[
        int,
        cyclopts.Parameter(
            "--hyperviscosity-order", help="Order of hyperviscosity (n in laplacian^n)."
        ),
    ] = 4,
    beta: Annotated[
        float, cyclopts.Parameter("--beta", help="Planetary vorticity gradient (beta).")
    ] = 10.0,
    rossby_radius: Annotated[
        float,
        cyclopts.Parameter("--rossby-radius", help="Rossby radius of deformation (R)."),
    ] = 0.1,
    t_end: Annotated[
        float, cyclopts.Parameter("--t-end", help="Final simulation time.")
    ] = 50.0,
    dt0: Annotated[
        float, cyclopts.Parameter("--dt0", help="Initial time step for adaptive solver.")
    ] = 1e-2,
    n_saves: Annotated[
        int, cyclopts.Parameter("--n-saves", help="Number of time points to save.")
    ] = 101,
    output_dir: Annotated[
        pathlib.Path | None,
        cyclopts.Parameter("--output-dir", help="Directory to save the output NetCDF."),
    ] = None,
):
    """Main function to run the 1.5-Layer QG simulation."""
    logger.info("=" * 60)
    logger.info("1.5-Layer Quasigeostrophic (QG) Model")
    logger.info("=" * 60)

    # --- Setup Grid, Operators, and Parameters ---
    logger.info("Setting up grid and operators...")
    grid = FourierGrid2D.from_N_L(Nx=nx, Ny=ny, Lx=domain_length, Ly=domain_length)
    deriv = SpectralDerivative2D(grid)
    solver_helmholtz = SpectralHelmholtzSolver2D(grid)
    logger.success(
        f"Grid initialized: {nx}x{ny}, Domain: {domain_length:.4f}x{domain_length:.4f}"
    )

    _, Y = grid.X
    planetary_vort = beta * Y
    r_def_inv_sq = 1.0 / (rossby_radius**2)

    params = Params(
        nu=viscosity,
        nv=hyperviscosity_order,
        beta=beta,
        r_def_inv_sq=r_def_inv_sq,
        grid=grid,
        deriv=deriv,
        solver=solver_helmholtz,
        forcing=None,
    )
    logger.info("Physical parameters:")
    logger.info(f"  - beta (planetary vorticity gradient): {beta}")
    logger.info(f"  - R (Rossby radius of deformation): {rossby_radius}")
    logger.info(f"  - nu (viscosity): {viscosity:.2e}")
    logger.info(f"  - n (hyperviscosity order): {hyperviscosity_order}")

    # --- Initial Condition: small random noise on a zonal jet ---
    logger.info("Generating random initial PV field...")
    q0 = generate_initial_pv(grid)
    y0 = State(q=q0)
    logger.success("Initial PV field generated (band-pass filtered noise)")

    # --- Time Integration Setup (IMEX) ---
    logger.info("Configuring time integration...")
    terms = diffrax.MultiTerm(
        diffrax.ODETerm(explicit_term), diffrax.ODETerm(implicit_term)
    )
    solver = diffrax.KenCarp4()
    stepsize_controller = diffrax.PIDController(rtol=1e-5, atol=1e-5)
    saveat = diffrax.SaveAt(ts=jnp.linspace(0, t_end, n_saves))
    logger.success(f"Time integration: t=[0, {t_end}], saving {n_saves} snapshots")
    logger.info("Solver: KenCarp4 (IMEX), Adaptive time-stepping with PID controller")

    # --- Run the Simulation ---
    logger.info("Running simulation...")
    sol = diffrax.diffeqsolve(
        terms,
        solver,
        t0=0,
        t1=t_end,
        dt0=dt0,
        y0=y0,
        args=params,
        saveat=saveat,
        stepsize_controller=stepsize_controller,
        max_steps=16**5,
    )
    logger.success(
        f"Simulation complete! Final time: {sol.ts[-1]:.4f}, "
        f"Steps taken: {sol.stats['num_steps']}"
    )

    # --- Post-processing and output ---
    logger.info("Post-processing results...")
    ds = build_dataset(sol, params, grid, planetary_vort)

    if output_dir is None:
        output_dir = pathlib.Path("./output/qg_model")
    output_dir.mkdir(parents=True, exist_ok=True)
    output_path = output_dir / "qg_sim.nc"
    ds.to_netcdf(output_path)
    logger.success(f"Output saved to: {output_path}")

    logger.info("Generating plots...")
    fig = plot_results(ds)
    fig.savefig(IMG_DIR / "pv_and_vorticity_evolution.png", dpi=150, bbox_inches="tight")
    logger.success("Plots generated successfully!")
    plt.show()

    return ds

@app.default def run_qg_model( nx: Annotated[ int, cyclopts.Parameter("--nx", help="Number of grid points in x-direction.") ] = 128, ny: Annotated[ int, cyclopts.Parameter("--ny", help="Number of grid points in y-direction.") ] = 128, domain_length: Annotated[ float, cyclopts.Parameter("--length", help="Length of the square periodic domain.") ] = 1.0, viscosity: Annotated[ float, cyclopts.Parameter("--viscosity", help="Kinematic viscosity (nu).") ] = 2e-12, hyperviscosity_order: Annotated[ int, cyclopts.Parameter( "--hyperviscosity-order", help="Order of hyperviscosity (n in laplacian^n)." ), ] = 4, beta: Annotated[ float, cyclopts.Parameter("--beta", help="Planetary vorticity gradient (beta).") ] = 10.0, rossby_radius: Annotated[ float, cyclopts.Parameter("--rossby-radius", help="Rossby radius of deformation (R)."), ] = 0.1, t_end: Annotated[ float, cyclopts.Parameter("--t-end", help="Final simulation time.") ] = 50.0, dt0: Annotated[ float, cyclopts.Parameter("--dt0", help="Initial time step for adaptive solver.") ] = 1e-2, n_saves: Annotated[ int, cyclopts.Parameter("--n-saves", help="Number of time points to save.") ] = 101, output_dir: Annotated[ pathlib.Path | None, cyclopts.Parameter("--output-dir", help="Directory to save the output NetCDF."), ] = None, ): """Main function to run the 1.5-Layer QG simulation.""" logger.info("=" * 60) logger.info("1.5-Layer Quasigeostrophic (QG) Model") logger.info("=" * 60) # --- Setup Grid, Operators, and Parameters --- logger.info("Setting up grid and operators...") grid = FourierGrid2D.from_N_L(Nx=nx, Ny=ny, Lx=domain_length, Ly=domain_length) deriv = SpectralDerivative2D(grid) solver_helmholtz = SpectralHelmholtzSolver2D(grid) logger.success( f"Grid initialized: {nx}x{ny}, Domain: {domain_length:.4f}x{domain_length:.4f}" ) _, Y = grid.X planetary_vort = beta * Y r_def_inv_sq = 1.0 / (rossby_radius**2) params = Params( nu=viscosity, nv=hyperviscosity_order, beta=beta, r_def_inv_sq=r_def_inv_sq, grid=grid, deriv=deriv, solver=solver_helmholtz, forcing=None, ) logger.info("Physical parameters:") logger.info(f" - beta (planetary vorticity gradient): {beta}") logger.info(f" - R (Rossby radius of deformation): {rossby_radius}") logger.info(f" - nu (viscosity): {viscosity:.2e}") logger.info(f" - n (hyperviscosity order): {hyperviscosity_order}") # --- Initial Condition: small random noise on a zonal jet --- logger.info("Generating random initial PV field...") q0 = generate_initial_pv(grid) y0 = State(q=q0) logger.success("Initial PV field generated (band-pass filtered noise)") # --- Time Integration Setup (IMEX) --- logger.info("Configuring time integration...") terms = diffrax.MultiTerm( diffrax.ODETerm(explicit_term), diffrax.ODETerm(implicit_term) ) solver = diffrax.KenCarp4() stepsize_controller = diffrax.PIDController(rtol=1e-5, atol=1e-5) saveat = diffrax.SaveAt(ts=jnp.linspace(0, t_end, n_saves)) logger.success(f"Time integration: t=[0, {t_end}], saving {n_saves} snapshots") logger.info("Solver: KenCarp4 (IMEX), Adaptive time-stepping with PID controller") # --- Run the Simulation --- logger.info("Running simulation...") sol = diffrax.diffeqsolve( terms, solver, t0=0, t1=t_end, dt0=dt0, y0=y0, args=params, saveat=saveat, stepsize_controller=stepsize_controller, max_steps=16**5, ) logger.success( f"Simulation complete! Final time: {sol.ts[-1]:.4f}, " f"Steps taken: {sol.stats['num_steps']}" ) # --- Post-processing and output --- logger.info("Post-processing results...") ds = build_dataset(sol, params, grid, planetary_vort) if output_dir is None: output_dir = pathlib.Path("./output/qg_model") output_dir.mkdir(parents=True, exist_ok=True) output_path = output_dir / "qg_sim.nc" ds.to_netcdf(output_path) logger.success(f"Output saved to: {output_path}") logger.info("Generating plots...") fig = plot_results(ds) fig.savefig(IMG_DIR / "pv_and_vorticity_evolution.png", dpi=150, bbox_inches="tight") logger.success("Plots generated successfully!") plt.show() return ds

6. Post-processing with xarray¶

In [ ]:

def build_dataset(
    sol, params: Params, grid: FourierGrid2D, planetary_vort
) -> xr.Dataset:
    """Assembles the simulation output into an xarray Dataset."""
    logger.info("Computing derived fields (psi, omega, u, v) for all time steps...")

    psi, u, v = jax.vmap(get_psi_and_uv_from_q, in_axes=(0, None))(sol.ys.q, params)
    relative_vorticity = jax.vmap(params.deriv.laplacian)(psi)

    X, Y = grid.X
    ds = xr.Dataset(
        data_vars={
            "q": (("time", "y", "x"), sol.ys.q + planetary_vort),
            "psi": (("time", "y", "x"), psi),
            "omega": (("time", "y", "x"), relative_vorticity),
            "u": (("time", "y", "x"), u),
            "v": (("time", "y", "x"), v),
        },
        coords={"time": sol.ts, "x": X[0, :], "y": Y[:, 0]},
        attrs={
            "description": "1.5-Layer Quasigeostrophic Model",
            "beta": params.beta,
            "rossby_radius": float(1.0 / params.r_def_inv_sq**0.5),
            "viscosity": params.nu,
            "hyperviscosity_order": params.nv,
        },
    )
    return ds

def build_dataset( sol, params: Params, grid: FourierGrid2D, planetary_vort ) -> xr.Dataset: """Assembles the simulation output into an xarray Dataset.""" logger.info("Computing derived fields (psi, omega, u, v) for all time steps...") psi, u, v = jax.vmap(get_psi_and_uv_from_q, in_axes=(0, None))(sol.ys.q, params) relative_vorticity = jax.vmap(params.deriv.laplacian)(psi) X, Y = grid.X ds = xr.Dataset( data_vars={ "q": (("time", "y", "x"), sol.ys.q + planetary_vort), "psi": (("time", "y", "x"), psi), "omega": (("time", "y", "x"), relative_vorticity), "u": (("time", "y", "x"), u), "v": (("time", "y", "x"), v), }, coords={"time": sol.ts, "x": X[0, :], "y": Y[:, 0]}, attrs={ "description": "1.5-Layer Quasigeostrophic Model", "beta": params.beta, "rossby_radius": float(1.0 / params.r_def_inv_sq**0.5), "viscosity": params.nu, "hyperviscosity_order": params.nv, }, ) return ds

7. Plotting¶

In [ ]:

def plot_results(ds: xr.Dataset):
    """Plots the PV and relative vorticity fields."""
    times_to_plot = ds.time.values[[0, len(ds.time) // 3, 2 * len(ds.time) // 3, -1]]

    fig = plt.figure(figsize=(11, 8))
    subfigs = fig.subfigures(1, 2, wspace=0.07)

    # Plot Potential Vorticity
    axes_q = subfigs[0].subplots(2, 2, sharex=True, sharey=True)
    subfigs[0].suptitle("Potential Vorticity (q)", fontsize=14)
    vmax_q = ds["q"].quantile(0.99)
    vmin_q = ds["q"].quantile(0.01)
    for i, t in enumerate(tqdm(times_to_plot, desc="Plotting PV")):
        ax = axes_q.flatten()[i]
        ds["q"].sel(time=t).plot.pcolormesh(
            ax=ax, cmap="RdBu_r", vmin=vmin_q, vmax=vmax_q, cbar_kwargs={"label": "PV"}
        )
        ax.set_title(f"Time = {t:.2f}")
        ax.set_aspect("equal")

    # Plot Relative Vorticity
    axes_om = subfigs[1].subplots(2, 2, sharex=True, sharey=True)
    subfigs[1].suptitle("Relative Vorticity (omega)", fontsize=14)
    vmax_om = ds["omega"].quantile(0.99)
    vmin_om = ds["omega"].quantile(0.01)
    for i, t in enumerate(tqdm(times_to_plot, desc="Plotting omega")):
        ax = axes_om.flatten()[i]
        ds["omega"].sel(time=t).plot.pcolormesh(
            ax=ax,
            cmap="RdBu_r",
            vmin=vmin_om,
            vmax=vmax_om,
            cbar_kwargs={"label": "omega"},
        )
        ax.set_title(f"Time = {t:.2f}")
        ax.set_aspect("equal")

    plt.tight_layout()
    return fig

def plot_results(ds: xr.Dataset): """Plots the PV and relative vorticity fields.""" times_to_plot = ds.time.values[[0, len(ds.time) // 3, 2 * len(ds.time) // 3, -1]] fig = plt.figure(figsize=(11, 8)) subfigs = fig.subfigures(1, 2, wspace=0.07) # Plot Potential Vorticity axes_q = subfigs[0].subplots(2, 2, sharex=True, sharey=True) subfigs[0].suptitle("Potential Vorticity (q)", fontsize=14) vmax_q = ds["q"].quantile(0.99) vmin_q = ds["q"].quantile(0.01) for i, t in enumerate(tqdm(times_to_plot, desc="Plotting PV")): ax = axes_q.flatten()[i] ds["q"].sel(time=t).plot.pcolormesh( ax=ax, cmap="RdBu_r", vmin=vmin_q, vmax=vmax_q, cbar_kwargs={"label": "PV"} ) ax.set_title(f"Time = {t:.2f}") ax.set_aspect("equal") # Plot Relative Vorticity axes_om = subfigs[1].subplots(2, 2, sharex=True, sharey=True) subfigs[1].suptitle("Relative Vorticity (omega)", fontsize=14) vmax_om = ds["omega"].quantile(0.99) vmin_om = ds["omega"].quantile(0.01) for i, t in enumerate(tqdm(times_to_plot, desc="Plotting omega")): ax = axes_om.flatten()[i] ds["omega"].sel(time=t).plot.pcolormesh( ax=ax, cmap="RdBu_r", vmin=vmin_om, vmax=vmax_om, cbar_kwargs={"label": "omega"}, ) ax.set_title(f"Time = {t:.2f}") ax.set_aspect("equal") plt.tight_layout() return fig

Run the Simulation¶

Configure parameters and execute. For interactive exploration, reduce nx/ny (e.g. 64) and t_end.

In [ ]:

# Default parameters for notebook execution
NX = 128
NY = 128
DOMAIN_LENGTH = 1.0
VISCOSITY = 2e-12
HYPERVISCOSITY_ORDER = 4
BETA = 10.0
ROSSBY_RADIUS = 0.1
T_END = 50.0
DT0 = 1e-2
N_SAVES = 101
OUTPUT_DIR = pathlib.Path("./output/qg_model")

# Default parameters for notebook execution NX = 128 NY = 128 DOMAIN_LENGTH = 1.0 VISCOSITY = 2e-12 HYPERVISCOSITY_ORDER = 4 BETA = 10.0 ROSSBY_RADIUS = 0.1 T_END = 50.0 DT0 = 1e-2 N_SAVES = 101 OUTPUT_DIR = pathlib.Path("./output/qg_model")

In [ ]:

logger.info("Setting up grid and operators...")
grid = FourierGrid2D.from_N_L(Nx=NX, Ny=NY, Lx=DOMAIN_LENGTH, Ly=DOMAIN_LENGTH)
deriv = SpectralDerivative2D(grid)
solver_helmholtz = SpectralHelmholtzSolver2D(grid)

_, Y_grid = grid.X
planetary_vort = BETA * Y_grid
r_def_inv_sq = 1.0 / (ROSSBY_RADIUS**2)

params = Params(
    nu=VISCOSITY,
    nv=HYPERVISCOSITY_ORDER,
    beta=BETA,
    r_def_inv_sq=r_def_inv_sq,
    grid=grid,
    deriv=deriv,
    solver=solver_helmholtz,
    forcing=None,
)

q0 = generate_initial_pv(grid)
y0 = State(q=q0)

terms = diffrax.MultiTerm(
    diffrax.ODETerm(explicit_term), diffrax.ODETerm(implicit_term)
)
solver_ode = diffrax.KenCarp4()
stepsize_controller = diffrax.PIDController(rtol=1e-5, atol=1e-5)
saveat = diffrax.SaveAt(ts=jnp.linspace(0, T_END, N_SAVES))

logger.info("Running simulation...")
sol = diffrax.diffeqsolve(
    terms,
    solver_ode,
    t0=0,
    t1=T_END,
    dt0=DT0,
    y0=y0,
    args=params,
    saveat=saveat,
    stepsize_controller=stepsize_controller,
    max_steps=16**5,
)
logger.success(f"Simulation complete! Steps taken: {sol.stats['num_steps']}")

logger.info("Setting up grid and operators...") grid = FourierGrid2D.from_N_L(Nx=NX, Ny=NY, Lx=DOMAIN_LENGTH, Ly=DOMAIN_LENGTH) deriv = SpectralDerivative2D(grid) solver_helmholtz = SpectralHelmholtzSolver2D(grid) _, Y_grid = grid.X planetary_vort = BETA * Y_grid r_def_inv_sq = 1.0 / (ROSSBY_RADIUS**2) params = Params( nu=VISCOSITY, nv=HYPERVISCOSITY_ORDER, beta=BETA, r_def_inv_sq=r_def_inv_sq, grid=grid, deriv=deriv, solver=solver_helmholtz, forcing=None, ) q0 = generate_initial_pv(grid) y0 = State(q=q0) terms = diffrax.MultiTerm( diffrax.ODETerm(explicit_term), diffrax.ODETerm(implicit_term) ) solver_ode = diffrax.KenCarp4() stepsize_controller = diffrax.PIDController(rtol=1e-5, atol=1e-5) saveat = diffrax.SaveAt(ts=jnp.linspace(0, T_END, N_SAVES)) logger.info("Running simulation...") sol = diffrax.diffeqsolve( terms, solver_ode, t0=0, t1=T_END, dt0=DT0, y0=y0, args=params, saveat=saveat, stepsize_controller=stepsize_controller, max_steps=16**5, ) logger.success(f"Simulation complete! Steps taken: {sol.stats['num_steps']}")

In [ ]:

ds = build_dataset(sol, params, grid, planetary_vort)

OUTPUT_DIR.mkdir(parents=True, exist_ok=True)
output_path = OUTPUT_DIR / "qg_sim.nc"
ds.to_netcdf(output_path)
logger.success(f"Output saved to: {output_path}")

fig = plot_results(ds)
fig.savefig(IMG_DIR / "pv_and_vorticity_evolution.png", dpi=150, bbox_inches="tight")
plt.show()

ds = build_dataset(sol, params, grid, planetary_vort) OUTPUT_DIR.mkdir(parents=True, exist_ok=True) output_path = OUTPUT_DIR / "qg_sim.nc" ds.to_netcdf(output_path) logger.success(f"Output saved to: {output_path}") fig = plot_results(ds) fig.savefig(IMG_DIR / "pv_and_vorticity_evolution.png", dpi=150, bbox_inches="tight") plt.show()

In [ ]:

if __name__ == "__main__":
    app()

if __name__ == "__main__": app()
